J2154A PerfectPulse® Differential TDR

Precise Differential or Single-Ended TDR – Time Domain Reflectometry in one convenient package
Compatible with the Picotest P2104A 1-port and P2105A TDR Browser Probes, as well as other manufacturers’ 50 Ohms probes
All applications requiring a fast, precise edge
Low cost
USB or battery-powered

Low-cost PCB coupon tester – Characteristic Impedance PCB traces
Measure cable and PCB trace length, characteristic impedance, and dielectric constant
Locate and detect impedance mismatches
Measure parasitic values of inductance and capacitance such as bond wires, vias, and ESL
Verify the integrity of cable crimps and connector launches
Measure PCB trace path rise/fall time and overshoot/undershoot
Supports cable and trace loss modeling
Troubleshoot clock jitter and crosstalk
Measure microwave filters
Test the frequency bandwidth, rise/fall time, and flatness of lab instruments and probes
